| Model型号 | DG10500SE | DG11000SE | DG11500SE | DG12000SE | |||
|---|---|---|---|---|---|---|---|
| Max Output最大输出(kW) | 8.0 | 8.5 | 9.0 | 10.0 | |||
| Rated Output额定输出(kW) | 7.5 | 8.0 | 8.5 | 9.5 | |||
| Rated AC Voltage额定电压(V) | 110/120,220,230,240,120/240,220/380,230/400,240/415 | ||||||
| Frequency频率(Hz) | 50 | ||||||
| Engine Speed转速(rpm) | 3000 | ||||||
| Power Factor功率因数 | 1 | ||||||
| DC Output直流输出(V/A) | 12V/8.3A | ||||||
| Phase相数 | Single Phase or Three Phase单相或三相 | ||||||
| Alternator Type电机形式 | Self-Excited自励磁 | ||||||
| Starting System启动系统 | Electric电启动 | ||||||
| Noise Level (dB at 7m)7米处噪音 | 70-73 dB | ||||||
| Fuel Tank Capacity燃油箱容量(L) | 25 | 25 | |||||
| Continuous Work持续工作小时(hr) | 12 | 12 | |||||
| Engine Model型号 | 1100F | 1103F | |||||
| Engine Type动力形式 | Single-Cylinder,Vertical,4-Stroke,Air-Cooled Diesel Engine单缸，直立，四冲程，风冷柴油机 | ||||||
| Displacement排量(cc) | 660 | 720 | |||||
| Bore×Stroke缸径×行程(mm) | 100×84 | 103×88 | |||||
| FuelConsumptionrate耗油率(g/kW/h) | ≤230 | ≤230 | |||||
| Fuel Type燃油 | 0#or-10#Light Diesel Oil O#或者-10#清洁柴油 | ||||||
| Lubrication Oil Volume润滑油容量(L) | 2.5 | ||||||
| Combustion System燃烧系统 | Direct Injection直喷式 | ||||||
| Standard Features标准配置 | Voltmeter,AC Output Socket,AC Circuit Breaker,Oil Alert电压表，交流插座，交流断路器，机油报警 | ||||||
| Optional Features选配 | Four Sides Wheels,Digital Meter,ATS,Remote Control万向轮，数控表，ATS,遥控启动 | ||||||
| Dimension包装尺寸(LxWxH)(mm) | A:1110×760×920 B:1120×645×920 | ||||||
| Gross Weight毛重(kg) | A:220 B:218 | A:222 B:220 | A:226 B:224 | A:225 B:223 | |||
